Insertion Type Electromagnetic Flow Meter

Product Description

Insertion Type Electromagnetic Flow Meters are economical alternatives to full-caliber electromagnetic flowmeters. It has a wide range of DN100mm-DN3000mm. It can be made with threaded ball valves or flanged ball valves and is suitable for hot tapping applications. It adopts the new technology of non-uniform magnetic field and special magnetic structure, the magnetic field is stable, and the volume and the weight is reduced, so that the flowmeter has the characteristics of small and light weight. It is not affected by power frequency and various stray interferences on site, and the work is very stable and reliable.

Advantages

Insertion Type Electromagnetic Flow Meter has the characteristics of reliable performance, high precision, low power consumption, stable zero point and convenient parameter setting. The measurement result has nothing to do with physical parameters such as flow velocity distribution, liquid pressure, temperature, density, and viscosity. In addition, the sensor induced voltage signal has a linear relationship with the average flow rate, so the measurement accuracy is high.

Features：

Price independent of pipe diameter

High accuracy 1.5%

Measuring range up to 15m/s

Pressure up to 16 bar

Bi-directional flow measurement

Automatic self-diagnosis

Protection Class: IP68 (sensor submersible) available

ABS/PP probe suitable for max 80degC

Applications：

Water & Wastewater

Petro Industry

Power Industry

Iron and Steel Industry
